EHS-1 L Holographic Sight
$499.99
The EHS-1 L takes the proven performance of our flagship holographic sight and streamlines it for shooters who prioritize a permanent, rock-solid interface. By replacing the Quick Detach lever with a robust cross-bolt rail attachment, the "L" variant offers a lower profile and a more traditional mounting solution without sacrificing the technical excellence of the original EHS-1.
What's included:
- EHS-1 L Holographic Sight
- Quick Reference Guide
- One CR123 Battery
PATENT PENDING
- SKU:
- EHS1-L-BLK-0165
- Availability:
- Orders typically ship within 24-48 hours of purchase.
Description
The EHS-1 L Enhanced Holographic Sight from Dynamic Optronic Technologies is engineered for professionals who demand absolute zero retention in the most rigorous tactical environments. Featuring a 1 MOA center dot and a 65 MOA outer ring, this optic provides the perfect balance of rapid target acquisition and long-range precision.
Housed in durable aircraft-grade aluminum with a hard-coat anodized finish, the EHS-1 L is built to endure. The new cross-bolt mounting system ensures a secure, high-torque connection to any MIL-STD-1913 (Picatinny) rail, making it an ideal choice for primary duty rifles where a permanent mount is preferred.
Beyond its rugged exterior, the optic features anti-reflective coated lenses with unlimited eye relief for maximum situational awareness. It is powered by a single CR123A battery providing 1,000 hours of continuous runtime, supported by Dynamic Wake motion activation and an auto shut-off function. For surgical accuracy, the windage and elevation settings are adjustable at 0.5 MOA per click. Furthermore, the unit is IP68-rated waterproof and dustproof, tested to maintain peak performance in extreme temperatures ranging from -40°F to 131°F.
The EHS-1 L delivers the same elite optical performance as the EHS-1, refined for those who value a streamlined, high-security mounting configuration.
Downloads
Technical Specification
Optical
Magnification: 1x
Eye Relief: Unlimited
Window Size: 1.2in x 0.8in (30.5mm x 20.5mm)
Reticle: 1 MOA Center Dot, 65 MOA
Wavelength: 650nm
Lens Coating: Anti-reflection coating, all surfaces
Electrical
Battery: CR123A
Continuous Working Hours:
≥ 1000 hours (medium brightness
Low Battery Warning:
Reticle begins flashing in-window
Mechanical
Material: Aircraft-grade Aluminum
Surface Finish: Anodize
Adjustment Range:
± 40 MOA windage/elevation
Adjustment Increment: 0.5 MOA
Size: 3.17in (H) x 1.86in (W) x 2.15in (D)
(81mm x 47mm x 55mm)
Centerline: 2.26in (57mm)
Weight: 234g (without battery)
Mount: Cross Bolt MIL-STD 1913 rail / Picatinny Rail
Environmental
Working Temperature: -40°F to 131°F (-40°C to 55°C)
Storage Temperature:
-40°F to 131°F (-40°C to 55°C)
Waterproofing: IP68
Related Products
DOT EHS-1 ARD
Options Available
$49.99
5 Reviews Write a Review
-
EHS-1L review from a nobody.
I’m a big Eotech guy first and foremost. Been very dedicated to them. This changes things a tad. Optic feels great out of the box. It’s sleek, feels pretty damn solid, and the optic height with a Magpul CTR stock is perfect for me. The optic functions fantastic but i have 2 gripes overall for those that care. Shake awake is meh, may or may not fall asleep on you. Fell asleep really quick while zeroing from a bench rest and at one point didn’t wake up unless i pressed +/- to wake it up. Second gripe is i wish there were lower level brightness settings. Tried zeroing at 50m but couldn’t get my dot low enough to not wash out my zeros POA. I think another lower lvl or two would be great. So far though i think this a viable option for anyone that prefers a more upright shooting position, wants a great optic that’s not too pricey, and wants a fast optic you can use with night vision. They have military discount too for those that are active or veteran. Good job DOT!
-
DOT EHS-1
I was curious when i fist saw it announced and bought my first dot over 4th of july and couldn't be happier it does everything my eotech does and more plus its the perfect height to use with my nods right out of the box no more extra bs riser needed its so good I've sold my eotech to buy another 10 out of 10 would DOT again
-
EHS -1L
I was hesitant at first as it was a new co and not sure i wanted to always be locked into 2.26 heights but decided to try it out. It is good to go and is super fast and the reticle does a good job of just floating in air and don’t even notice the housing and on night vision this thing really shines, i personally think it is as good as Eotech . I looks really nice under nods!! My only complaint would be i think a more in depth owners Manuel would be helpful. I haven’t had long enough to know about the battery life yet. I haven’t used most of the dots and holographic sights out in the last 30 years and I don’t regret buying this one at all, it is good to go. I mounted this on a KAC cqb 11.5 and paired with a 3eir designate V and it is light and fast just the way i want it.
-
Shake awake at a great price
The EHS-L 1 is my first holographic optic, and I'm glad I chose this one. Customer service is great. The price is even better. The branded packaging is cool - very useful pluck foam hard case. They loaded the shipping box with some stickers and sealed it with anti tamper tape. Overall a perfect buying experience.
-
Solid Construction
Haven't shot too much since receiving this but the construction seems solid and has held up well to rapid sequences of fire.
